Hydraulic Shearing Machine

Power Press (C Type)
Modal
(JSM-H)		 Cutting Capacity
M.S.		 Cutting Length
mm		 No. of Hold Downs Rake Angle Deg. No. of Stroke Backauge Motor HP Lenght Height Width
1504 4 1500 7 0.5 - 2.5 10 to 14 750 7.5 2000 1650 975
1506 6 1500 7 0.5 - 2.5 10 to 14 750 10 2000 1650 975
2004 4 2000 9 0.5 - 2.5 10 to 14 750 7.5 2500 1650 975
2006 6 2000 9 0.5 - 2.5 10 to 14 750 10 2500 1650 975
2008 8 2000 9 0.5 - 2.5 10 to 14 750 10 2500 1850 975
2010 10 2000 9 0.5 - 2.5 8 to 12 750 15 2500 1850 975
2013 13 2000 9 0.5 - 2.5 8 to 12 750 15 2500 2050 975
2016 16 2000 9 0.5 - 2.5 8 to 12 750 20 2500 2050 975
2504 4 2500 11 0.5 - 2.5 10 to 14 750 7.5 3000 1650 975
2506 6 2500 11 0.5 - 2.5 10 to 14 750 10 3000 1650 975
2508 8 2500 11 0.5 - 2.5 10 to 14 750 10 3000 1650 975
2510 10 2500 11 0.5 - 2.5 10 to 14 750 15 3000 1850 975
2513 13 2500 11 0.5 - 2.5 8 to 12 750 15 3000 2050 975
2516 16 2500 11 0.5 - 2.5 8 to 12 750 20 3000 2050 975
3104 4 3000 13 0.5 - 2.5 10 to 14 750 7.5 3500 1650 975
3106 6 3000 13 0.5 - 2.5 10 to 14 750 10 3500 1650 975
3108 8 3000 13 0.5 - 2.5 8 to 12 750 10 3500 1850 975
3110 10 3000 13 0.5 - 2.5 7 to 10 750 15 3500 1850 975
3113 13 3000 13 05. - 2.5 7 to 10 750 15 3500 2050 1200
3116 16 3000 13 0.5 - 2.5 7 to 10 750 20 3500 2050 1200
4106 6 4000 18 0.5 - 2.5 7 to 10 750 10 4600 2050 1200
4108 8 4000 18 0.5 - 2.5 6 to 8 750 15 4600 2050 1200
4110 10 4000 18 0.5 - 2.5 6 to 8 750 15 4600 2050 1200

Product Range
