| Capacity In Tons | 10 | 20 | 30 | 50 | 75 | 100 | 150 | 200 | 250 | 300 |
|---|---|---|---|---|---|---|---|---|---|---|
| Table Size | 305 × 406 |
375 × 505 |
450 × 600 |
505 × 710 |
535 × 750 |
600 × 900 |
710 × 1000 |
815 × 1150 |
850 × 1200 |
915 × 1350 |
| Distance Between Bed to Ram | 205 | 250 | 280 | 305 | 355 | 400 | 450 | 500 | 550 | 600 |
| Stroke Length (Adjustable) | 50 | 65 | 75 | 90 | 100 | 110 | 125 | 150 | 150 | 175 |
| Adjustment in Slide | 25 | 28 | 30 | 40 | 45 | 50 | 55 | 65 | 70 | 75 |
| Shank Hole | 28 | 30 | 35 | 40 | 45 | 50 | 55 | 65 | 70 | 75 |
| No. Of Strokes (RPM) | 50 | 50 | 45 | 45 | 40 | 40 | 35 | 30 | 25 | 20 |
| Height From Floor To Topof Bolster | 750 | 750 | 750 | 750 | 750 | 750 | 800 | 825 | 850 | 850 |
| Bed Opening (Dia) | 100 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 275 | 300 |
| Motor Power HP/RPM | 2/1440 | 2/1440 | 3/1440 | 5/1440 | 7.5/1440 | 10/1440 | 15/1440 | 20/1440 | 25/1440 | 30/1440 |
| Motor Pulley (Dia) | B-5 | B-5 | B-5 | B-6 | B-6 | B-7 | C-7 | C-8 | C-8 | C-9 |
